#include <CylindricalCellGeometry.hpp>
Public Types | |
| enum class | MassType : int { MassDensity , Mass , NumberDensity , Number } |
Public Member Functions | |
| bool | autoRevolve () const |
| MassType | massType () const |
| int | numAutoRevolveBins () const |
| Public Member Functions inherited from ImportedGeometry | |
| double | density (Position bfr) const override |
| string | filename () const |
| Position | generatePosition () const override |
| bool | importMetallicity () const |
| bool | importTemperature () const |
| double | maxTemperature () const |
| int | numSites () const override |
| double | SigmaX () const override |
| double | SigmaY () const override |
| double | SigmaZ () const override |
| Position | sitePosition (int index) const override |
| string | useColumns () const |
| Public Member Functions inherited from GenGeometry | |
| int | dimension () const override |
| Public Member Functions inherited from SimulationItem | |
| template<class T> | |
| T * | find (bool setup=true) const |
| template<class T> | |
| T * | interface (int levels=-999999, bool setup=true) const |
| virtual string | itemName () const |
| void | setup () |
| string | typeAndName () const |
| Public Member Functions inherited from Item | |
| Item (const Item &)=delete | |
| virtual | ~Item () |
| void | addChild (Item *child) |
| const vector< Item * > & | children () const |
| virtual void | clearItemListProperty (const PropertyDef *property) |
| void | destroyChild (Item *child) |
| virtual bool | getBoolProperty (const PropertyDef *property) const |
| virtual vector< double > | getDoubleListProperty (const PropertyDef *property) const |
| virtual double | getDoubleProperty (const PropertyDef *property) const |
| virtual string | getEnumProperty (const PropertyDef *property) const |
| virtual int | getIntProperty (const PropertyDef *property) const |
| virtual vector< Item * > | getItemListProperty (const PropertyDef *property) const |
| virtual Item * | getItemProperty (const PropertyDef *property) const |
| virtual string | getStringProperty (const PropertyDef *property) const |
| int | getUtilityProperty (string name) const |
| virtual void | insertIntoItemListProperty (const PropertyDef *property, int index, Item *item) |
| Item & | operator= (const Item &)=delete |
| Item * | parent () const |
| virtual void | removeFromItemListProperty (const PropertyDef *property, int index) |
| virtual void | setBoolProperty (const PropertyDef *property, bool value) |
| virtual void | setDoubleListProperty (const PropertyDef *property, vector< double > value) |
| virtual void | setDoubleProperty (const PropertyDef *property, double value) |
| virtual void | setEnumProperty (const PropertyDef *property, string value) |
| virtual void | setIntProperty (const PropertyDef *property, int value) |
| virtual void | setItemProperty (const PropertyDef *property, Item *item) |
| virtual void | setStringProperty (const PropertyDef *property, string value) |
| void | setUtilityProperty (string name, int value) |
| virtual string | type () const |
| Public Member Functions inherited from SiteListInterface | |
| virtual | ~SiteListInterface () |
Protected Member Functions | |
| CylindricalCellGeometry () | |
| Snapshot * | createAndOpenSnapshot () override |
| Protected Member Functions inherited from ImportedGeometry | |
| ImportedGeometry () | |
| ~ImportedGeometry () | |
| void | setupSelfAfter () override |
| Protected Member Functions inherited from GenGeometry | |
| GenGeometry () | |
| Protected Member Functions inherited from Geometry | |
| Geometry () | |
| Random * | random () const |
| void | setupSelfBefore () override |
| Protected Member Functions inherited from SimulationItem | |
| SimulationItem () | |
| virtual bool | offersInterface (const std::type_info &interfaceTypeInfo) const |
| Protected Member Functions inherited from Item | |
| Item () | |
| Protected Member Functions inherited from SiteListInterface | |
| SiteListInterface () | |
Private Types | |
| using | BaseType |
| using | ItemType |
Private Attributes | |
| bool | _autoRevolve |
| MassType | _massType |
| int | _numAutoRevolveBins |
Friends | |
| class | ItemRegistry |
A CylindricalCellGeometry instance represents a 3D geometry with a spatial density distribution described by a list of cylindrical cells lined up with the cylindrical coordinate axes; refer to the CylindricalCellSnapshot class for more information. The cell data is usually extracted from a cosmological simulation snapshot, and it must be provided in a column text file formatted as described below. The total mass in the geometry is normalized to unity after importing the data.
Refer to the description of the TextInFile class for information on overall formatting and on how to include header lines specifying the units for each column in the input file. In case the input file has no unit specifications, the default units mentioned below are used instead. The number of columns in the input file depends on the options configured by the user for this CylindricalCellGeometry instance:
\[ R_\mathrm{min}\,(\mathrm{pc}) \quad \varphi_\mathrm{min}\,(\mathrm{deg}) \quad z_\mathrm{min}\,(\mathrm{pc}) \quad R_\mathrm{max}\,(\mathrm{pc}) \quad \varphi_\mathrm{max}\,(\mathrm{deg}) \quad z_\mathrm{max}\,(\mathrm{pc}) \quad \{\, \rho\,(\text{M}_\odot\,\text{pc}^{-3}) \;\;|\;\; M\,(\text{M}_\odot) \;\;|\;\; n\,(\text{cm}^{-3}) \;\;|\;\; N\,(1) \,\} \quad [Z\,(1)] \quad [T\,(\mathrm{K})] \]
The first six columns specify the coordinates of the bordering planes and cylinders of the cell. The autoRevolve property controls a feature to automatically revolve 2D data to 3D. See the CylindricalCellSnapshot class for more information.
Depending on the value of the massType option, the seventh column lists the average mass density \(\rho\), the integrated mass \(M\), the average number density \(n\), or the integrated number density \(N\) for the cell. The precise units for this field are irrelevant because the total mass in the geometry will be normalized to unity after importing the data. However, the import procedure still insists on knowing the units.
If the importMetallicity option is enabled, the next column specifies a "metallicity" fraction, which in this context is simply multiplied with the mass/density column to obtain the actual mass/density of the cell. If the importTemperature option is enabled, the next column specifies a temperature. If this temperature is higher than the maximum configured temperature, the mass and density of the cell are set to zero, regardless of the mass or density specified in the seventh column. If the importTemperature option is disabled, or the maximum temperature value is set to zero, such a cutoff is not applied.
This item type is displayed only if the Boolean expression "Level2" evaluates to true after replacing the names by true or false depending on their presence.
|
strong |
The enumeration type indicating the type of mass quantity to be imported.
MassDensity : "mass density".
Mass : "mass (volume-integrated mass density)".
NumberDensity : "number density".
Number : "number (volume-integrated number density)".
|
inlineprotected |
Default constructor for concrete Item subclass CylindricalCellGeometry: "a geometry imported from cylindrical cell data".
|
inline |
This function returns the value of the discoverable Boolean property autoRevolve: "automatically revolve 2D data to a 3D model".
The default value for this property is given by the conditional value expression "false".
|
overrideprotectedvirtual |
This function constructs a new CylindricalCellGeometry object, calls its open() function, configures it to import a mass or density column, and finally returns a pointer to the object. Ownership of the Snapshot object is transferred to the caller.
Implements ImportedGeometry.
|
inline |
This function returns the value of the discoverable MassType enumeration property massType: "the type of mass quantity to be imported".
The default value for this property is given by the conditional value expression "MassDensity".
|
inline |
This function returns the value of the discoverable integer property numAutoRevolveBins: "the number of azimuth bins for auto-revolving 2D data".
This property is relevant only if the Boolean expression "autoRevolve" evaluates to true after replacing the names by true or false depending on their presence.
The minimum value for this property is "2".
The maximum value for this property is "1024".
The default value for this property is given by the conditional value expression "16".
